Technical parameters
The type of light source Visual laser diode with a wavelength of 650nm
Scan mode Single-line scanning
Scan speed 2 ± 200 times per second
Scan accuracy 0.10mm(pcs0.9)
The width of the scan 30mm@ the scanner window, 220mm@200mm
Scan depth of view 0-250mm (0.33mm. PCS 90%)
Corner. 30°
Elevation. 65°
Angle. 55°
Decoding capability EAN-8, EAN-13, UPC-A, UPC-E, Code 39, Code 93, Code 128, EAN128, Codaber, Industoal 2 of 5, Interleave 2 of 5, Matrix 2 of 5, MSI, China post code, etc.
The interface is supported Printer USB connector
Print contrast A minimum reflection difference of 30%.
Error rate 1/ 50 million
How to prompt Buzzer INDICATOR
How to scan Manual always-on self-sensing
Physical parameters
Form factor Length× width × height: 165mm × 66mm × 95mm
Weight. 180g
Material. ABS+PC
Cable standard Line: 1.65m
Electrical parameters
Voltage. 5V
The working current 85mA
Static current 36mA
Laser safety In line with the national secondary laser safety standards
Electromagnetic compatibility CE & FCC DOC compliance
Environment parameters
Operating temperature 0°C -45°C
Storage temperature -20°C -60°C
Humidity. Relative humidity 5%-95% (no condensation)
Ambient brightness Max.5,000 Lux (fluorescence)
Seismic capacity Can withstand 1.5m drops in the air
