Battery capacity2000mA
Wireless distance50-100 meters
Wireless storage5000-20000 number of visual characters
Wireless standby30 days
Wireless continuous workMore than 72 hours
Transport mode2.4G or Bluetooth, USB charging cable can be used as a wired data transfer
The type of light sourceVisual laser diode with a wavelength of 650nm
Scan modeSingle-line scanning
Scan speed2 ± 200 times per second
Scan accuracy0.10mm(pcs0.9)
The width of the scan30mm@ the scanner window, 220mm@200mm
Scan depth of view0-250mm (0.33mm. PCS 90%)
Corner30°
Elevation65°
Angle55°
Decoding capabilityEAN-8, EAN-13, UPC-A, UPC-E, Code 39, Code 93, Code 128, EAN128, Codaber, Industoal 2 of 5, Interleave 2 of 5, Matrix 2 of 5, MSI, China post code, etc.
The interface is supportedPrinter USB connector
Print contrastA minimum reflection difference of 30%.
Error rate1/ 50 million
How to promptBuzzer INDICATOR
How to scanManual always-on self-sensing
Form factorLength× width × height: 160mm × 66mm × 90mm
Weight180g
MaterialABS+PC
Cable standardLine: 1.5m
Voltage5V
The working current85mA
Static current36mA
Laser safetyIn line with the national secondary laser safety standards
Electromagnetic compatibilityCE & FCC DOC compliance
Operating temperature0°C -45°C
Storage temperature-20°C -60°C
HumidityRelative humidity 5%-95% (no condensation)
Ambient brightnessMax.5,000 Lux (fluorescence)
Seismic capacityCan withstand airdrops of 1.5m
