Technical parameters |
|
|
Battery capacity |
2000mA |
|
Wireless distance |
50-100m |
|
Wireless storage |
The number of visual characters ranges from 5000-20000 |
|
Wireless standby |
30 days |
|
Wireless continuous operation |
Over 72 hours |
|
Transfer mode |
2.4g wireless, USB charging cable can be used as a wired data transfer |
|
The light source type |
Visual laser diode, wavelength 650nm |
|
Scanning mode |
Single line scan |
|
Scanning speed |
200 + 2 times per second |
|
Scanning accuracy |
0.10 mm (pcs0.9) |
|
The scanning width |
30mm@ scanner window, 220mm@200mm |
|
Scanning depth of field |
0-250 – mm (0.33 mm) PCS 90%) |
|
Around the corner |
30° |
|
elevation |
65° |
|
Angle |
55° |
|
Decoding ability |
Ean-8, EAN-13, UPC-A, UPC-E, Code 39, Code 93, Code 128, EAN128, Codaber, Industoal 2 of 5, Interleave 2 of 5, Matrix 2 of 5, MSI, China post code, etc. |
|
Support interface |
Printer USB interface |
|
Print contrast |
Minimum 30% reflection error |
|
ber |
1/5000000 |
|
prompt |
Buzzer indicator |
|
Scanning way |
Manual normally on |
|
Physical parameters |
|
|
Overall dimensions |
Length x width x height: 165mm x 66mm x 95mm |
|
The weight of the |
180g |
|
The material |
ABS+PC |
|
Cable standard |
Line: 1.65 m |
|
Electrical parameters |
|
|
voltage |
5V |
|
Working current |
400mA |
|
The static current |
36mA |
|
Laser safety |
In line with the national secondary laser safety standards |
|
Electromagnetic compatibility |
CE & FCC DOC compliance |
|
Environmental parameters |
|
|
Working temperature |
0℃ – 45℃ |
|
Storage temperature |
– 20℃ to 60℃ |
|
humidity |
Relative humidity 5%-95% (without condensation) |
|
Environmental brightness |
Max.5,000 Lux |
|
Earthquake resistance |
Can withstand a drop of 1.5m |
